100G QSFP28 LR4 for Juniper JNP-QSFP-100G-LR4 100GBASE-LR4 QSFP28 Transceiver Module SMF 1310nm LAN WDM 10km LC DOM
Product details
| Management number | 209093312 | Release Date | 2026/03/29 | List Price | $140.00 | Model Number | 209093312 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【Wide Compatibility】It's fully compliant and compatible for Juniper networks QSFP28 MSA, SFF-8665 and SFF-8636, IEEE 802.3ba 100GBASE-LR4 and IEEE 802.3bm CAUI-4 standards, coding as Juniper JNP-QSFP-100G-LR4
- 【100G QSFP+ LR4】100GBASE-LR4 QSFP+ transceiver module, up to 10km over a standard pair of single mode fiber (SMF) with duplex LC connectors, long distance transmission over singlemode fiber 1310nm, 4 independent full-duplex channels, Hot Pluggable, DDM Built-in digital diagnostic functions, Class 1 FDA Laser Safety and RoHS Compliant. 0°C to 70°C(32 to 158°F)
- 【Connector&Cable】100GBASE-LR4 QSFP+ transceivers use duplex single mode SMF fiber patch cables with duplex LC connectors hot pluggable, but not SC connector. It support single mode fibers OS2 SMF up to 10km.
- 【SR4 vs LR4】The main difference between 100GBASE-SR4 QSFP28 and 100GBASE-LR4 QSFP28 is the transmission distance and connector type. The 100GBASE-SR4 QSFP28 supports 70m@OM3/100m@OM4 transmission with MTP/MPO connector; while the100GBASE-LR4 QSFP28 supports 10km@SMF transmission with LC duplex connector.
- 【Widely Application】 It's fully compliant QSFP28 MSA, RoHS, IEEE 802.3ba 100GBASE-LR4 and IEEE 802.3bm CAUI-4 standards, widely used on Infiniband QDR and DDR interconnects, large data centers Interconnect, high-performance computing networks, enterprise core and distribution layer applications.
| Item Weight | 1.76 ounces |
|---|---|
| Manufacturer | Fiber-Store |
| Item model number | QSFP28-100G-LR4-JU |
| Product Dimensions | 5.5 x 2.4 x 1.2 inches |
